Your First Hydra

Posted on October 10, 2018

So you’ve started using Nix for your projects. The reproducible builds and dependency management are predictable and declarative. For the first time in a long time the ground at your feet feels firm, you’re no longer treading quicksand. You size up your nemesis, the Continuous Integration server, long has it defied your attempts to build as you do… No longer.

This post is a guide for setting up a small local instance of the Nix powered CI system known as Hydra:

Hydra is a Nix-based continuous build system, released under the terms of the GNU GPLv3 or (at your option) any later version. It continuously checks out sources of software projects from version management systems to build, test and release them. The build tasks are described using Nix expressions. This allows a Hydra build task to specify all the dependencies needed to build or test a project. It supports a number of operating systems, such as various GNU/Linux flavours, Mac OS X, and Windows.

Hydra Homepage

Hydra is a very powerful system, and like most powerful systems it can be difficult to know where to start. This post aims to help by walking through the process of setting up a local Hydra instance on a virtual machine. This will be a stand-alone Hydra instance, only a single machine without build slaves.

‘Why did it need to have eight heads?’, you ponder briefly before deciding you’d rather not know…

Requirements

This tutorial was tested on a machine running NixOS, which is not required, but you will need:

To install nixops:

$ nix-env -i nixops

You should be comfortable writing your own Nix expressions and debugging failures. This is still somewhat of a bleeding edge part of the Nix ecosystem, so things don’t always go according to plan.

NixOps

To manage the Hydra machine, we’re going to leverage NixOps to create, start, run, and update our virtual machine. This lets us have a declarative defintion of our build machine, as well as a consistent interface for managing the machine(s).

We’re going to create two Nix expressions that together define our machine:

  1. The virtual machine environment: simple_hydra_vbox.nix
  2. The configuration of the Hydra machine: simple_hydra.nix

The virtual machine

This will be a ‘headless’ VirtualBox machine, with some settings to keep the overall size of the machine down, and control access.

We must create a Nix attrset that contains a function that defines our machine, this function is attached to a name that will be used as the <HOSTNAME> of the machine within NixOps. We use the name my-hydra here, and we’ll need to use that name again when we write our machine configuration.

# START simple_hydra_vbox.nix
{
  my-hydra =
    { config, pkgs, ... }: {

NixOps lets you choose your deployment target, ours being VirtualBox. NixOps supports quite a few different environemnts. Check out the NixOps Manual for more information on supported target environments.

      deployment.targetEnv = "virtualbox**;

Click here to find out more about why deployment and similar attributes are used this way:

Note that deployment is not passed in as an argument to our configuration. This is intentional and forms part of an idiomatic Nix technique for building and overriding attributes. We build a set of attributes with a specific predefined structure, such that NixOps can union them together, then act upon those settings to create the machines we’ve specified.

As an example, say we have some “default” settings in an attrset somewhere:

defaultAttrs = { fieldA = "generic_name";
, fieldB = "foo";
, fieldC = 3000;
}

To override only fieldB, we create the following attrset in our expression:

myAttrs = { fieldB = "bar"; }

Then when the attrset values are combined, the original default values can be overridden like so:

# (//) is a built in Nix function to union two attrsets together
defaultAttrs // myAttrs
=
{ fieldA = "generic_name";
, fieldB = "bar";
, fieldC = 3000;
}

The ordering of the union matters, myAttrs // defaultAttrs would override the values in the other direction.

This is action is recursive, nested properties are combined as part of this process.

({ fieldA = 3000; fieldB = { nestedA = "foo"; }; }) // ({ fieldB.nestedA = "bar"; })
=
{ fieldA = 3000; fieldB = { nestedA = "bar"; }; }

This capability allows you to have all of the settings you want and you need only ever specify the precise ones you need to alter. This can then be combined with other attrsets that alter other settings for a long chain of overrides to end up with a final set. Such as this contrived example:

defaultMachineConf
// ({ machine.cpus = 2; })          # "hardware" settings in one file
// ({ machine.os.user = "Sally"; }) # "software" settings in a different file

Next we tweak the settings for our VirtualBox machine. The machine will need a fair chunk of memory, as evaluating the nixpkgs tree to build the dependencies can be expensive. Also, as with any CI system, you need to make sure your target has sufficient resources to actually run the required builds.

      deployment.virtualbox.memorySize = 4096;
      deployment.virtualbox.vcpu = 2;

Our machine doesn’t require a GUI so we enable headless mode. Note that these are virtualbox specific settings, each target will have their own collection of options, check the manual for more information.

      deployment.virtualbox.headless = true;

We’ll also turn off the manual from appearing on the machine, this saves a bit more space. Enable a time daemon, ntp. Then set the access controls for SSH, disallowing SFTP and password based authentication.

      services.nixosManual.showManual         = false;
      services.ntp.enable                     = false;
      services.openssh.allowSFTP              = false;
      services.openssh.passwordAuthentication = false;

Provide some settings for the users on the machine. The mutableUsers option means that every time the system is deployed the user information will be completely replaced by the static definition from this file. The next setting for keyFiles will copy the listed SSH key files to the target machine. These files are expected to exist on the machine where the nixops command is being executed.

In this example we’re going to copy across an RSA public key from a pair. This allows us to use nixops ssh -d <deployment-name> <machine-name> to access the machine via SSH.

      users = {
        mutableUsers = false;
        users.root.openssh.authorizedKeys.keyFiles = [ ~/.ssh/id_rsa.pub ];
      };
    };
}
# END: simple_hydra_vbox.nix

We put all of the above in a file named simple_hydra_vbox.nix, this will form part of the input for our nixops command later on. This is the machine, but that isn’t much good without a definition for what will actually be running on the machine.

Next we will define the NixOS configuration that will be running on our virtual machine. This will include our Hydra service, as well as its dependencies, with some caveats because we’re running on a local, virtualised machine.

A basic Hydra

What follows is a NixOps expression for a stand-alone Hydra build machine. It is enough to start your own Hydra instance with a binary cache. There are sections which are required for running this machine in a virtual machine, but we’ll cover those as we go. This machine will not define any build slaves, so it will build and cache everything locally.

As before, we write a nix expression that is a function that produces an attrset that is our machine configuration. Note that the name we assign matches the virualisation configuration. This must match otherwise there will be an error from NixOps. This attribute is also used as the machine hostname, so any where you see <HOSTNAME> in the configuration, replace that with this name.

# START: simple_hydra.nix
{
  my-hydra =
    { config, pkgs, ...}: {

As Hydra is able to send emails for various events, so our machine will need some sort of email capability. We enable the postfix service like so:

services.postfix = {
    enable = true;
    setSendmail = true;
};

The build queues and parts of the jobset configuration are all stored in a postgres database on the Hydra machine, so we need to enable the postgresql service, and provide a mapping from NixOS users to PostgreSQL users. Otherwise Hydra won’t be able to access the database!

services.postgresql = {
    enable = true;
    package = pkgs.postgresql;
    identMap =
      ''
        hydra-users hydra hydra
        hydra-users hydra-queue-runner hydra
        hydra-users hydra-www hydra
        hydra-users root postgres
        hydra-users postgres postgres
      '';
};

This next setting is to tell NixOS to open the TCP port for accessing the web interface for Hydra. We don’t need to add the postfix or ssh ports in this instance because the postfix and virtualisation configuration will add them on our behalf.

    networking.firewall.allowedTCPPorts = [ config.services.hydra.port ];

Now onto the meaty part of creating our Hydra configuration, enabling and configuring the hydra service.

services.hydra = {
    enable = true;
    useSubstitutes = true;
    hydraURL = "https://hydra.example.org";
    notificationSender = "hydra@example.org";

The hydraURL setting is the page for the Hydra web interface, it is also used in emails as the root path for any links back to this Hydra system. The notificationSender setting is the from address of emails from this Hydra system.

The useSubstitutes setting is a bit more complicated, it’s best to refer to the manual for this one:

Whether to use binary caches for downloading store paths. Note that binary substitutions trigger (a potentially large number of) additional HTTP requests that slow down the queue monitor thread significantly. Also, this Hydra instance will serve those downloaded store paths to its users with its own signature attached as if it had built them itself, so don’t enable this feature unless your active binary caches are absolute trustworthy.

— From https://nixos.org/nixos/options.html#services.hydra.usesubstitutes

With this enabled you will reap the benefits of cached build dependencies, and spare precious cycles by not constantly rebuilding things unnecessarily. The trade-off is a higher number of HTTP requests that may affect the running of the Hydra system. Depending on how active your build queue is, this may be a cause for concern.

The following setting is important and required (even though it is empty). Because we’re building a stand-alone Hydra instance, we have to explicitly tell Hydra that there are no additional build machines.

Without this setting, Hydra will ignore our machine definition and the Hydra instance will be not function, as the expected build machine configuration does not match reality.

buildMachinesFiles = [];

We provide some extraConfig to tell Hydra where to place the binary cache and its secret key.

    extraConfig = ''
      store_uri = file:///var/lib/hydra/cache?secret-key=/etc/nix/<HOSTNAME>/secret
      binary_cache_secret_key_file = /etc/nix/<HOSTNAME>/secret
      binary_cache_dir = /var/lib/hydra/cache
    '';
};

See here (https://nixos.org/nixos/options.html#services.hydra) for a full list of the options available for the Hydra service in NixOS.

The following is optional, but here for example purposes about using nginx to serve the Hydra web interface. This Hydra instance was running locally in a VM so this isn’t needed. The full scope of Nginx configuration and what is available via NixOS is well beyond this post.

services.nginx = {
  enable = true;
  recommendedProxySettings = true;
  virtualHosts."hydra.example.org" = {
    forceSSL = true;
    enableACME = true;
    locations."/".proxyPass = "http://localhost:3000";
  };
};

Hydra requires manual steps beyond the configuration of the NixOS service. This is only a one time requirement however. We leverage a systemd service to manage the timing. This provides some additional guarantees that the final configuration will run after Hydra is installed and running.

The initial options describe our systemd service.

systemd.services.hydra-manual-setup = {
  description = "Create Admin User for Hydra";
  serviceConfig.Type = "oneshot";
  serviceConfig.RemainAfterExit = true;
  wantedBy = [ "multi-user.target" ];
  requires = [ "hydra-init.service" ];
  after = [ "hydra-init.service" ];
  environment = builtins.removeAttrs (config.systemd.services.hydra-init.environment) ["PATH"];

This is the script that is run by the systemd service, we predicate its execution on the lack of existence of a .setup-is-complete file.

  script = ''
    if [ ! -e ~hydra/.setup-is-complete ]; then
      # create signing keys
      /run/current-system/sw/bin/install -d -m 551 /etc/nix/<HOSTNAME>
      /run/current-system/sw/bin/nix-store --generate-binary-cache-key <HOSTNAME> /etc/nix/<HOSTNAME>/secret /etc/nix/<HOSTNAME>/public
      /run/current-system/sw/bin/chown -R hydra:hydra /etc/nix/<HOSTNAME>
      /run/current-system/sw/bin/chmod 440 /etc/nix/<HOSTNAME>/secret
      /run/current-system/sw/bin/chmod 444 /etc/nix/<HOSTNAME>/public
      # create cache
      /run/current-system/sw/bin/install -d -m 755 /var/lib/hydra/cache
      /run/current-system/sw/bin/chown -R hydra-queue-runner:hydra /var/lib/hydra/cache
      # done
      touch ~hydra/.setup-is-complete
    fi
  '';
};

As we indicated in the extraConfig section of Hydra, we’re going to have a binary store on this machine. This is where we generate the secret keys and create the cache itself.

Next we set some explict nix settings to schedule the garbage collection of the store, and also the automatically optimise the store. Which means that nix will remove duplicate files from the store, replacing them with hard links to a single copy.

nix.gc = {
  automatic = true;
  dates = "15 3 * * *"; # [1]
};

nix.autoOptimiseStore = true;

[1]: This is a CRON schedule. To find out more you can read the crontab manual or the Wikipedia page.

This tells NixOS which users have privileged access to the nix store. These users can add additional binary caches.

nix.trustedUsers = ["hydra" "hydra-evaluator" "hydra-queue-runner"];

Lastly, we define a build machine so that Hydra has a ‘builder’ to orchestrate. In this example we’re building locally so our hostName is “localhost”. Use the systems setting to indicate the systems or architectures that we able to build for, and maxJobs to set the maximum number of build processes.

The supportedFeatures property is a list of “Features” that this build machine supports. If a derivation is submitted that requires features that are not supported on a given build machine then it will not be built.

    nix.buildMachines = [
      {
        hostName = "localhost";
        systems = [ "x86_64-linux" "i686-linux" ];
        maxJobs = 6;
        # for building VirtualBox VMs as build artifacts, you might need other
        # features depending on what you are doing
        supportedFeatures = [ ];
      }
    ];
  };
}
# END: simple_hydra.nix

Place all of that configuration in a file called simple_hydra.nix and we’re ready to start powering up.

Powering up

Now to tell NixOps to create and prepare our Hydra instance.

$ cd <path to 'simple_hydra' nix files>
$ ls
simple_hydra.nix simple_hydra_vbox.nix
Create the virtual machine within NixOps

Before you can initiate the deployment of your machine, you need to make NixOps aware of it:

$ nixops create ./simple_hydra.nix ./simple_hydra_vbox.nix -d simple_hydra
created deployment ‘5537e9ba-cabf-11e8-80d0-d481d7517abf’ ### This hash will differ for your machine
5537e9ba-cabf-11e8-80d0-d481d7517abf

If that completes without error, you can then issue the following command to NixOps:

$ nixops info -d simple_hydra
Network name: simple_hydra
Network UUID: 5537e9ba-cabf-11e8-80d0-d481d7517abf
Network description: Unnamed NixOps network
Nix expressions: /path/to/simple_hydra.nix /path/to/simple_hydra_vbox.nix

+----------|---------------|------------|-------------|------------+
| Name     |     Status    | Type       | Resource Id | IP address |
+----------|---------------|------------|-------------|------------+
| my-hydra | Missing / New | virtualbox |             |            |
+----------|---------------|------------|-------------|------------+

The info command for nixops provides feedback about the status of the machine(s) you have deployed, their IP addresses, and other things. This information is stored local to the machine that issued this nixops command, it is not shared between different deployment machines. So even if you deploy to AWS using nixops, someone else that has the same nix expressions for your machines will not have any knowledge of their deployment status.

Trigger deployment of the virtual machine

We can now instruct nixops to deploy the configuration to the virtual machines, this part may take a while. Once you issue the following command you might like to get up, go for a walk, stretch, or fetch a cup of your favourite beverage.

The --force-reboot is required to ensure the Hydra services are started correctly. If you do not include it then the deployment phase will complete successfully, but it will report an error as not all of the services will have been initiated correctly.

This flag is also required to ensure everything ticks over as required, as there are some nixops errors that can be avoided or resolved by simply power cycling the machine.

The -d flag that we give to nixops is to specify the name of the deployment we want to use. If you don’t provide this information then nixops will return this error:

error: state file contains multiple deployments, so you should specify which one to use using ‘-d’, or set the environment variable NIXOPS_DEPLOYMENT

You can set the environment variable NIXOPS_DEPLOYMENT to simple_hydra if you don’t want to include the -d simple_hydra information every time.

$ nixops deploy -d simple_hydra --force-reboot

NixOps will then set about the task of creating the virtual machine, initialising all the disks and network settings etc. Then create the configuration prior to copying to the newly minted machine. After which, barring any errors you should see the following text:

my-hydra> waiting for the machine to finish rebooting...[down]......................[up]
my-hydra> activation finished successfully
simple_hydra> deployment finished successfully

Once the machine is deployed, you can check its status using $ nixops info -d simple_hydra.

Network name: simple_hydra
Network UUID: c58245b3-cac2-11e8-9346-d481d7517abf
Network description: Unnamed NixOps network
Nix expressions: /path/to/simple_hydra.nix /path/to/simple_hydra_vbox.nix

+----------|-----------------|------------|------------------------------------------------------|----------------+
| Name     |      Status     | Type       | Resource Id                                          | IP address     |
+----------|-----------------|------------|------------------------------------------------------|----------------+
| my-hydra | Up / Up-to-date | virtualbox | nixops-c58245b3-cac2-11e8-9346-d481d7517abf-my-hydra | 192.168.56.101 |
+----------|-----------------|------------|------------------------------------------------------|----------------+

This deployment depends on the files containing the nix expressions that were used to create it, if those files disappear then you will not be able to destroy or update the machine via NixOps.

If you want to make changes to these machines or configuration, such as adding a CPU, or changing the port for the Hydra web UI. You make the change in those files, then you only have to issue the deploy command again and NixOps will take care of updating the machine to the new configuration.

If things have gone according to plan then you should be able to point a browser at the Hydra web UI. The address will be the default Hydra port of 3000 at the IP address listed in the output from the nixops info -d simple_hydra command. Using the above output as an example the address for the Hydra page is: http://192.168.56.101:3000.

We’re ready to start adding some jobsets to our Hydra instance, but there is a bit of a problem as we can’t login to our Hydra UI.

Add the Hydra admin user

To add an admin user to Hydra, we use the hydra-create-user program that is included with Hydra. This must be run on the Hydra machine itself, so we need to SSH in or send the instruction over SSH.

The nixops ssh command lets you do both:

To run the command on the machine by connecting first, run the following:

$ nixops ssh -d simple_hydra my-hydra

This will put you on the machine at a prompt as root on the my-hydra machine from the simple_hydra deployment. You can then run the create user command.

Alternatively you can simply send the single instruction over SSH:

$ nixops ssh -d simple_hydra my-hydra '<create-user-command>'
creating new user `admin`

Putting the command in quotes after the nixops ssh command will send a single instruction over SSH, printing any output.

The command to create an admin user is:

$ hydra-create-user admin \
    --full-name "Bobby Admin" \
    --email-address "bobby@example.org" \
    --password TOTALLYSECURE \
    --role admin

With successful output being something like:

creating new user `admin`

You can now use these credentials to login to your Hydra web UI and start configuring your jobsets and other Hydra settings. We plan to cover more information about writing your own declarative jobsets in a future post.

For the impatient or curious, you can have a look at the setup we use at QFPL for some of our projects:

One prepared earlier

If you’re looking at most of the code in this post and thinking that all it would take is some simple inputs and interpolation then you wouldn’t need to write the same nix expressions every time. You would be correct, and Will Fancher - known in some online communities as ElvishJerricco - has done just that in simple-hydra. This repo has a version of what we have worked through here, but abstracted so that you need only specify some choices along with hostnames etc.

For the sake of your own understanding, it is useful to work through it yourself first so you can more readily experiment and learn about the inner workings.

Going further

For those looking for more advanced Hydra information, the Hydra Tutorial by Github user peti is an excellent resource. The tutorial is also worked through as part of a presentation linked to from the repo: (presentation link).

That tutorial sets up a more complex Hydra configuration with a ‘master’ machine and ‘slave’ machines, in what would more closely resemble a real world setup.

We’re using functional programming to set up the infrastructure that we use from day to day.
