Reflexive Art

Sean Chalmers

Queensland Functional Programming Lab

sean.chalmers@data61.csiro.au

The Goals

Introduce Reflex svg and canvas libraries.
Show Haskell is capable of front-end art & animation.
Encourage / inspire you to take the plunge!

Generative and Evolutionary Art

Predominantly computer generated
Repetitive algorithm influenced by random or external input
A fascinating rabbit hole

familiar

Title: Substrate
Source: Complexification

bizarre

Title: Coloured Trails (Point Advection & Rendering)
Source: Entagma

simple

Title: Tiled Lines
Image: This Presentation
Technique: Generative Artistry

Why Haskell?

Cool Types
- Clever Types
  - Silly Types
    - Types that climb on rocks
      - Functions as values

        Lenses

        GHC/GHCJS

        traverse

Why Reflex?

Functional Reactive Programming
Flexible and powerful technique for describing interactions over time
Check the references for some links
Come to the workshop tomorrow!!

The basics

Event : a value at a point in time.
Behaviour : a value at all points in time.
Dynamic : Combination of an Event and a Behaviour.
- Unique to Reflex.
'Primitives' for creating and manipulating the above
Lean heavily on existing abstractions:
- Functor, Applicative, Monad, and friends.

Tiled Lines - Canvas

Basic Idea

Draw a line of predetermined length
Decide to turn 90\(^{\circ}\) left or right
Draw a line of predetermined length
Repeat \({(size/step)^2}\) times

Draw a line

JavaScript

context.beginPath();
context.moveTo(a,b);
context.lineTo(c,d);
context.closePath();
context.stroke();

Use ghcjs-dom package for API functions
No need to write manual FFI calls!

Haskell

beginPath context
moveTo context a b
lineTo context c d
closePath context
stroke context

Requesting a Canvas Context

We need a canvas rendering context:

Create your canvas

(canvas, _) <- RD.divClass "canvas-wrapper" $
  RD.elAttr' "canvas" canvasAttrs RD.blank

Ask reflex-dom-canvas for a 2d drawing context

dContext2d :: ... => CanvasConfig 'TwoD t -> m (Dynamic t (CanvasInfo 'TwoD t))

C.dContext2d (CTypes.CanvasConfig canvas mempty)

Yay!

data CanvasInfo (c :: ContextType) t = CanvasInfo
  { _canvasInfo_El      :: RD.El t
  , _canvasInfo_context :: RenderContext c
  ...

random Have i ? can

Decide to turn left or right…

data LR
  = LeftToRight
  | RightToLeft
  deriving (Show, Eq)

ltor1 :: IO LR
ltor1 = MRnd.uniform [RightToLeft, LeftToRight]

ltor2 :: Rnd.StdGen -> (LR, Rnd.StdGen)
ltor2 = first (bool RightToLeft LeftToRight . (>= 0.5))
  . Rnd.randomR (0::Double,1.0)

ltor3 :: MonadIO m => m LR
ltor3 = bool RightToLeft LeftToRight . (>= (0.5::Double))
  <$> liftIO (Rnd.randomRIO (0::Double,1.0))

Glorious loops

Repeat, lots.

imperative, mutable

for (var x = 0; x < size; x += step) {
  for (var y = 0; y < size; y += step) {
  }
}

functional, immutable

let xy = [0,stp .. size]

forM_ xy $ \x ->
  forM_ xy $ \y ->

Glorious lines

requestDomAction :: DomRenderHook t m => Event t (JSM a) -> m (Event t a)

_ <- requestDomAction $
  current (drawSteps <$> dCx) <@ ePost

Step input

Create a text input for our step size

dStepSize <- RD._textInput_value
  <$> B.bsNumberInput "Step Size" "step-size" defStepSize

Step bump

Add some buttons

eInc <- B.bsButton_ "+ Step" B.Primary
eDec <- B.bsButton_ "- Step" B.Primary

eInc, eDec :: Event t ()

Step state

Keep track of the step size as it changes over time.

dStep <- R.foldDyn ($) (fromIntegral defStepSize) $ R.mergeWith (.)
  [ incSize <$> eStepSize eInc
  , decSize <$> eStepSize eDec
  ]

foldDyn :: (... t, ... m) => (a -> b -> b) -> b -> Event t a -> m (Dynamic t b)

eStepSize eTrigger =
  R.fmapMaybe (readMaybe . Text.unpack) $ R.current dStepSize <@ eTrigger

Wiring it in

_ <- requestDomAction $
  current (drawSteps <$> dStep <*> dCx) <@ ( ePost <> eStep )

Drawing the lines

drawSteps stp cap cx = do
  DOM_CR.clearRect cx 0 0 (fromIntegral size) (fromIntegral size)
  DOM_CR.beginPath cx

  let xy = [0,stp .. size]

  forM_ xy $ \x ->
    forM_ xy $ \y ->
      draw x y stp cap cx

  DOM_CR.stroke cx

Squares - SVG

Source: Benjamin Kovach

Basic Idea

Randomly place a bunch of squares such that none intersect
Randomly apply colouring and fill to each square
Apply perlin noise to the corners of the squares

Ewww, strings

Using custom elements in reflex-dom is stringly

elAttr "rect" ("x" =: "30" <> "y" =: "40" <> "width" =: "100" <> "height" =: "200") blank

The element tag and properties must be given as Text values
Typos abound!

Introducing `reflex-dom-svg`

This package provides data types for:
- All the basic shapes: rect, path, circle, …
- Their required and some optional properties
- A DSL for creating path properties
- The animate element
It also provides functions, lenses, and prisms to make your life easier

Thus

What was sad

... "rect" ("x" =: "30" <> "y" =: "40" <> "width" =: "100" <> "height" =: "200")

Becomes happy

data SVG_Rect = SVG_Rect
  { _svg_rect_pos_x          :: Pos X
  , _svg_rect_pos_y          :: Pos Y
  , _svg_rect_width          :: Width
  , _svg_rect_height         :: Height
  , _svg_rect_cornerRadius_x :: Maybe (CornerRadius X)
  , _svg_rect_cornerRadius_y :: Maybe (CornerRadius Y)
  }

Put the G in SVG

To put a basic shape on the page

-- No child elements
svgBasicDyn_ :: s -> (p -> Map Text Text) -> Dynamic t p -> m (SVGEl t s)

-- Only allow a subset of SVG elements as possible child elements
svgBasicDyn  :: s -> (p -> Map Text Text) -> Dynamic t p
  -> Dynamic t (Map (CanBeNested s) (Map Text Text))
  -> m (SVGEl t s)

Looks like

SVG.svgBasicDyn_
  SVG.Rect          -- Indicate we want a '<rect>' element
  SVG.makeRectProps -- Use the library provided function for handling properties
  dMyRectProps      -- Provide a Dynamic of our SVG_Rect

Data structures for great justice

We will use a polygon for our squares

data SVG_Polygon = SVG_Polygon
  { _svg_polygon_start :: (Pos X, Pos Y)
  , _svg_polygon_path  :: NonEmpty (Pos X, Pos Y)
  }

We benefit from all the delicious existing abstractions
- Functor, Applicative, Traversable

Apply the perlin noise function to every point in a polygon

Given

newtype Poly = Poly
  { unPoly :: (PolyAttrs, SVG_Polygon) }
  deriving (Eq,Show)
makeWrapped ''Poly

We can lens & traverse our way to victory!

over (_Wrapped . _2) (
  (SVGT.svg_polygon_start %~ addNoise seed scale)
. (SVGT.svg_polygon_path . traverse %~ addNoise seed scale)
)

Gift keeps giving

reflex provides additional functionality for collections

simpleList :: Dynamic t [v] -> (Dynamic t v -> m a) -> m (Dynamic t [a])

So if you have a list of polygons that will change over time…

dPolys :: Dynamic t (NonEmpty Poly)
dPerlin :: Dynamic t (Poly -> Poly)

-- Polygons are kept in a 'NonEmpty' list so we always have something to draw
RD.simpleList (NE.toList <$> dPolys) $ \dPoly ->
  -- Apply the shifting perlin noise function to our polygon
  SVG.svgBasicDyn_ SVG.Polygon makePolyProps (dPerlin <*> dPoly)

Moving parts

We have a few things to juggle:

Maximum number of squares to be generated
Changing 'scale' value for use in the perlin noise function
Automatic or manual update to element properties

Square Count

rec (dSqCount, eSqCountChg) <- RD.divClass "sqr-inc-dec" $ do
      eIncSq <- B.bsButton_ "+ Sqr" B.Info
      _      <- RD.dynText $ (<> "# Squares") . tshow . unCount <$> dSqCount
      eDecSq <- B.bsButton_ "- Sqr" B.Info

      dSqrs <- RD.foldDyn ($) sqCount $ RD.mergeWith (.)
        [ incSqCount <$ eIncSq
        , decSqCount <$ eDecSq
        ]

Scale Input

dScaleInp <- RD.divClass "scale-slider" $ do
  RD.text "Scale"
  fmap (fmap realToFrac . RD._rangeInput_value) . RD.rangeInput $ B.rangeInpConf 0.0 "scale"
    & RD.rangeInputConfig_attributes . mapped %~ \m -> m
        & at "step" ?~ "0.0001"
        & at "min" ?~ "0.0"
        & at "max" ?~ "0.1"

Toggle

dFoofen <- RD.holdDyn dScaleInp $ RD.leftmost
  [ dScaleInp <$ eOnButton
  , dScaleRange <$ eOnTick
  ]

Game of Life - WebGL

Source Chris Wellons

Basic idea

Alright, so brace yourself, but what about…

Conway's 'Game of Life'…
But running in a fragment shader…
On the GPU…
eh?
eh?

Shift yaks

Focus is no longer on drawing actions
Now it is orchestration of actions that draw

Basic idea redux

Initialise two framebuffers
Populate one with random values
Run the fragment shader (which contains the game of life)
- Execute the game of life for each pixel
- Render the result to a framebuffer, not the screen
Paint the other framebuffer to the screen
Flip the framebuffers
Repeat

Initialising WebGL

Context
Shaders - needs compiling
Programs - needs linking

Don't forget

We're
not
writing
javascript.

Monad transformers, woo

We can have nicer things.

newtype WebGLM a = WebGLM
  { runWebGLM :: ExceptT Error JSM a
  }
  deriving ( Functor
           , Applicative
           , Monad
#ifdef ghcjs_HOST_OS
           , MonadIO
#else
           , MonadIO
           , MonadJSM
#endif
           , MonadError Error
           )

liftGLM :: Either Error a -> WebGLM a
liftGLM = either throwError pure

nb: MonadJSM ~ MonadIO when building with GHCJS.

Unremarkable code

initShader
  :: GHCJS.GLenum
  -> Getter s Text
  -> s
  -> WebGLRenderingContext
  -> WebGLM WebGLShader
initShader sType sL source cx = do

initProgram
  :: VertSrc
  -> FragSrc
  -> WebGLRenderingContext
  -> WebGLM WebGLProgram
initProgram vs fs cx = do

Code unremarkable

Check for errors

ok <- GHCJS.liftJSM . GHCJS.fromJSValUnchecked =<<
  GLB.getShaderParameter cx (Just s) GLB.COMPILE_STATUS

ok <- GHCJS.liftJSM . GHCJS.fromJSValUnchecked =<<
  GLB.getProgramParameter cx (Just p) GLB.LINK_STATUS

Lean on abstractions to handle plumbing

vs' <- initShader GLB.VERTEX_SHADER (to unVertSrc) vs cx
fs' <- initShader GLB.FRAGMENT_SHADER (to unFragSrc) fs cx
GLB.attachShader cx (Just p) (Just vs')
GLB.attachShader cx (Just p) (Just fs')

Abstraction to `Event`

Reflex helps out here too:

fanEither :: ... => Event t (Either a b) -> (Event t a, Event t b)

createGOL :: ... => WebGLRenderingContext -> m (Either Error GOL)

(eError, eGol) <- fmap R.fanEither . RD.requestDomAction $
  R.current (createGOL <$> dCx) <@ ePost

eError :: Event t Error
eGol :: Event t GOL

Fork in the graph

An error - Bugger
An initialised environment - Woot
Reflex comes out to play, again.
Switching
There are efficiency benefits too, as disconnected pieces of the graph are garbage collected

Only what we need

The FP way, narrow your focus/function to a smaller problem.

One to display the error
```
golError :: ... => Error -> m ()
```

One to run the orchestration for our WebGL

golRender :: ... => GOLInfo t -> StdGen -> GOL -> m ()

Making the choice

_ <- RD.widgetHold (RD.text "Nothing Ready Yet.") $ R.leftmost
  [ golError                                            <$> eError
  , golRender (GOLInfo eReset eStepOnce dTick dCx) sGen <$> eDrawn
  ]

Manage change

Let Reflex manage our GOL record in a Dynamic

dGOL <- R.holdDyn gol' $ R.leftmost
  [ eStepRendered
  , eWasReset
  ]

Updated on a step or reset Event

eStepRendered :: Event t GOL
eWasReset     :: Event t GOL

Step / Reset

step            :: ... =>           WebGLRenderingContext -> GOL -> m GOL
setInitialState :: ... => StdGen -> WebGLRenderingContext -> GOL -> m GOL

eStepRendered <- glRun step . R.switchDyn $ _golAuto golInfo
eWasReset     <- glRun (setInitialState sGen) $ _golReset golInfo

glRun f eGo = RD.requestDomAction $ R.current
  ( (\c -> f c >=> draw c)
    <$> _golCx golInfo
    <*> dGOL
  ) <@ eGo

Recursive Definition

golRender golInfo sGen gol' = mdo
  dGOL <- R.holdDyn gol' $ R.leftmost
    [ eStepRendered
    , eWasReset
    ]

  let
    glRun f eGo = RD.requestDomAction $ R.current
      ( (\c -> f c >=> draw c)
        <$> _golCx golInfo
        <*> dGOL
      ) <@ eGo

  eStepRendered <- glRun step . R.switchDyn $ _golAuto golInfo
  eWasReset     <- glRun (setInitialState sGen) $ _golReset golInfo

Wrapping Up

Nice bits

FP graphics, in the browser?! IT WORKS!!1eleventy!
Being able to use Mozilla Developer Network (MDN) docs is awesome
Hackage is full of awesome packages
- linear
- Clay
- colour

Sticky bits

Some types don't line up: ArrayBufferView doesn't exist in JS
Some optional function arguments… aren't

Snip of MDN for Canvas 2D fill function

void ctx.fill([fillRule]);
void ctx.fill(path[, fillRule]);

Type of fill from ghcjs-dom for 2D Canvas

fill :: ... => CanvasRenderingContext2D -> Maybe CanvasWindingRule -> m ()

Have at it!

From here, many good things can come.

Games
Charts
More art
All driven by the power of FP
Nothing can stop you, try something

Thank you. :)

References

Reflex
- Workshop by Dave Laing, Day 2 - ComposeConf 2018!!
- https://github.com/reflex-frp/reflex-platform
- https://github.com/obsidiansystems/obelisk
- https://blog.qfpl.io/posts/reflex/basics/introduction/
MDN docs
- https://developer.mozilla.org/en-US/docs/Web/API
WebGL
- Game of Life in a Fragment Shader https://nullprogram.com/blog/2014/06/10/

…and so many more, please come and ask!

Reflexive Art

Sean Chalmers

Queensland Functional Programming Lab

sean.chalmers@data61.csiro.au

The Goals

Generative and Evolutionary Art

familiar

bizarre

simple

Why Haskell?

Why Reflex?

The basics

Tiled Lines - Canvas

Basic Idea

Draw a line

Requesting a Canvas Context

random Have i ? can

Glorious loops

Glorious lines

Step input

Step bump

Step state

Wiring it in

Drawing the lines

Squares - SVG

Basic Idea

Ewww, strings

Introducing reflex-dom-svg

Thus

Put the G in SVG

Data structures for great justice

Gift keeps giving

Moving parts

Square Count

Scale Input

Toggle

Game of Life - WebGL

Basic idea

Shift yaks

Basic idea redux

Initialising WebGL

Don't forget

Monad transformers, woo

Unremarkable code

Code unremarkable

Abstraction to Event

Fork in the graph

Only what we need

Making the choice

Manage change

Step / Reset

Recursive Definition

Wrapping Up

Nice bits

Sticky bits

Have at it!

References

Introducing `reflex-dom-svg`

Abstraction to `Event`
